T-PS12-0905
9 Way Power Distribution Box -12VDC/10A
12VDC, 9 X 1000mA fused outlets (10A Max)

  (Gold Price?)
Enter Qty
Features
  • Switch Mode Power Supply
  • Input Voltage can be selected between 110V and 220V
  • Voltage Adjustment
  • Earth Connection
  • AC Input (Brown=Live, Blue=Neutral,Green=Ground)
  • Panel Isolation Switch ON/OFF
  • Std CCTV Camera Connection (up to 1100mA)
  • Parallel CCTV Camera Connection (For CCTV Camera’s rated at more than 500mA) If the CCTV Camera is rated at more than 1000mA multiple outputs can be connected in parallel to increase the total output current. In the example shown 3 outputs have been connected in parallel to give a total output of 2Amp.
  • To disable a camera output move the jumper link to the off position
  • Protection Fuses
    FOR INDOOR USE ONLY

Specification
Input Voltage AC100~120V AC220~240V
Output Current 9 X 1000mA fused outlets (10A Max), 12VDC
Output Power 60W
Dimensions 240mm(L) X 210mm (W) X 65mm(H)
